Description
Product Features
1.Pure sine wave solar inverter 2.Built-in 40A MPPT solar charger 3.PVinput voltage range20-150VDC (for 1000W),30~150VDC(for 1500W)Built-in anti-dust kit for harsh environment 4.Smart battery charge design to optimize battery life 5.meet rich customized demands 6.Solar energy is provided directly to the load first
|
Model
|
VICTOR NMS-1000-12
|
VICTOR NMS-1500-24
|
|
RATED POWER
|
1000W/1000VA
|
1500W/1500VA
|
|
AC Input
|
||
|
Voltage
|
230VAC
|
|
|
Selectable Voltage Range
|
170~280VAC(For Personal Computers)
|
|
|
90~280VAC(For Home Appliances)
|
||
|
Frequency Range
|
50Hz/60Hz(Autosensing)
|
|
|
AC OUTPUT
|
||
|
AC Voltage Regulation
|
230VAC±5%
|
|
|
Surge Power
|
2000VA
|
3000VA
|
|
Efficiency(Peak) PV to IN V
|
98%
|
|
|
Efficiency(Peak) Battery to IN V
|
94%
|
|
|
Transfer Time
|
10ms
|
|
|
BATTERY
|
||
|
Battery Voltage
|
12VDC
|
24VDC
|
|
Floating Charge Voltage
|
13.5VDC
|
27VDC
|
|
Overcharge Protection
|
16VDC
|
32VDC
|
|
SOLAR CHARGER&AC CHARGER
|
||
|
Solar Charger Type
|
MPPT
|
|
|
Maximum PV Array Power
|
600W
|
1200W
|
|
MPPT Range@Operating Voltage
|
20~150VDC
|
30-150VDC
|
|
Maximum PV Array Open Circuit
Voltage solar |
150VDC
|
|
|
Maximum Solar Charging Current
|
40A
|
|
|
Maximum AC Charging Current
|
40A
|
|
|
Maximum Solar+AC Charging
Current |
80A
|
|
|
PHYSICAL
|
||
|
Dimension， D*W*H(mm)
|
290*240*91
|
|
|
Cartoon Dimension， D“W*H(mm)
|
340*295*145
|
|
|
Net Weight(kgs)
|
3.5
|
3.6
|
|
Gross Weight(kgs}
|
4.0
|
4.2
|
|
ENVIRONMENT
|
||
|
Humidity
|
5%to 95%Relative Humidity(Non-condensing)
|
|
|
Operating Temperature
|
-10℃-50℃
|
|
|
STANDARD
|
||
|
Compliance Safety
|
CE
|
|
